page 44 — J36e2 elecTric WalK-BeHiND TrOWel • OperaTiON aND parTs maNUal — rev. #0 (07/24/12)
gearbOx assy.
10
1
6
7
8
8
4
5
2
3
4
7
9
11
18
18
19
19
20
21
22
13
13
23
30
25
29 26
27
28
8
31
12
12
7
1
6
7
6
9
GEARBOX
OIL
22 OZ.
(650 mL)
1
APPLY THREAD LOCK, LOCTITE
242 BLUE P/N 60091 OR EQUIVALENT.
7
NOTES:
GASKET AND SEAL KIT INCLUDES
ITEMS 1,4, 25, AND 29 PLUS GASKETS.
2
APPLY THREAD LOCK, LOCTITE
572 WHITE P/N 60096 OR EQUIVALENT.
3 TORQUE TO 15 FT-LBS (20 Nm)
4
GASKETS ARE NOT SOLD SEPARATELY.
SHIM (GASKETS) AS NECESSARY FOR
INPUT SHAFT END-PLAY.
5
GASKETS ARE NOT SOLD SEPARATELY.
SHIM (GASKETS) AS NECESSARY FOR
OUTPUT SHAFT END-PLAY.
6
USE SPECIALLY FORMULATED
WHITEMAN GEARBOX LUBRICANT
P/N 10139 OR ISO OIL.
GEARBOX
REQUIRES 26 OZ. (.76 LITERS)
OF GEARBOX LUBRICANT FOR
OPERATION. .
8
BEARING KIT INCLUDES ITEMS 6,7,18
AND 19.
GEARBOX ASSEMBLY ITEM 30,
INCLUDES ITEMS WITHIN DASHED LINE
EXCEPT ITEMS 12,13 AND 31
9
4
4
4
5
17
1 3
2
14
33
32
34
35
