HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 81
enGine fuel assy.
NO. paRT NO. paRT Name qTy. RemaRKS
1 4514 SCREW, HHC 1/4-20 X 5/8 .............................. 4 .......OLD STYLE COMET CLUTCH
1 1579 SCREW, HHC 1/4-20 X .5 ................................ 4 .......NEW STYLE MULTI-CLUTCH
2 0161 C WASHER, LOCK, 5/16 MED. ........................... 4 .......OLD STYLE COMET CLUTCH
3 0948 WASHER, FLAT, 1/4 SAE ................................ 4 .......OLD STYLE COMET CLUTCH
3 0948 WASHER, FLAT 1/4 SAE ................................ 12 ......NEW STYLE MULTI-CLUTCH
4 11418 FUEL CAP/GAUGE (10.5”) .............................. 1 .......S/N ZA020476761013007 AND BELOW
5 12404 TANK, HNN 5GAL ............................................ 1 .......S/N ZA020476761013007 AND BELOW
6 19633 BUSHING, RUBBER FUEL DAPCO10672 1
7 19661 VALVE , FUEL DRAIN DAPCO 11478 1
8 19473 CLAMP, WORM HOSE, #4 (1/4-5/8) 6
9 60013 HOSE, .25ID RUBBER FUEL LINE 3
10 11984 IN-LINE FUEL FILTER 5/16 1
11 10024 NUT, NYLOC 1/4-20 2
12 0131 A SCREW, HHC 1/4-20 X 3/4 2
13 12497 FUEL PUMP 1
14 0131 A SCREW, HHC 1/4-20 X 3/4 .............................. 4 .......NEW STYLE MULTI-CLUTCH
15 22588 MOUNT, FUEL TANK ....................................... 1 .......NEW STYLE MULTI-CLUTCH
16 10024 NUT, NYLOC 1/4-20 ......................................... 4 .......NEW STYLE MULTI-CLUTCH
17 19266 NUT, BLIND 1/4-20 X 10GA 4
18 22077 TANK,FUEL W/A-5 GAL EPA/CARB ................ 1 .......S/N ZA020476761013008 AND ABOVE
19 22205 RACHET CAP, TOP VENT ............................... 1 .......S/N ZA020476761013008 AND ABOVE
20 22081 SHUTOFF VALVE, 1/4 NPT, 1/4 HOSE ............ 1 .......S/N ZA020476761013008 AND ABOVE
21 16185 FITTING, PLUG 1/4MP SQ HD ........................ 1 .......S/N ZA020476761013008 AND ABOVE
