HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 77
enGine ClutCh assy. (Old style)
NO. paRT NO. paRT Name qTy. RemaRKS
1 20138 BELT, CVT-VANGUARD COMET ...........................2................ORDER 2 BELTS FOR SPARES
7 3911758 ADAPTOR, CLUTCH 31 HP VANGUARD 1
8 20046 SCREW, HHC M8 125 X 25 MM GRADE 10.9 5
9 12878 CLUTCH, CVT 1-7/16 COMET ..............................1................NO LONGER AVAILABLE
..................................................................................................USE CLUTCH KIT P/N 22581
..................................................................................................TO UPGRADE TO
..................................................................................................MULTI-CLUTCH SYSTEM
10 20215 .415 OD X 21/32 ID X 2-1/16L 1
11 4703 WASHER, LOCK, 5/8 MED 1
12 20057 SCREW, HHC 5/8-18 X4 1
13 23291 TOOL, CLUTCH REMOVAL 1
NOTICE
Multi-Clutch components are not interchangeable with the prior Hoffco
Comet drive system. The Hoffco Comet CVT system must be replaced
with Multi-Clutch components in the event of a Hoffco Comet clutch failure.
