HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 59
GearBOx assy.
NOTICE
+ S/N BI0203468 AND BELOW
, BI0203469 AND ABOVE, AND S/N BH0203412
NO.
paRT NO.
paRT Name
qTy.
RemaRKS
25$# 12700
SEAL, CASE 0-RING HHN 0.103 X 46. 38
1
26$%# 12701
SEAL, NATIONAL #471424
1
27$# 12702
SEAL, NATIONAL #470682
1
28$@ 12735
KEY, 3/8 X 3/4
1
29$+ 12736
KEY, HARDENED 3/8 X 1-1/2
1
30
+
12796
BEARING, CONE TIMKEN #26882
2
30
,
$+ 21801
BEARING, CONE SKF 33109 Q
2
31
+
12797
BEARING, CUP TIMKEN #26823
2
32
+
$ 20932
SHIM, INPUT. 0.002 THICK
3
32
,
$ 21800
SHIM, INPUT. 0.002 THICK
3
33$% 1313
SCREW, FHSC 3/8 - 24 X 3/4 PLAIN
1
34$% 26034
KEY, 3/16 X 17/32
1
35
+
$ 4196
SCREW, HHC 3/8 - 16 X 3/4
8
36$
911064
FITTING, PLUG 1/2 MP SQ HEAD
1
37$
911329
FITTING, PLUG 3/8 MP MAGNETIC
2
38$% 9120
RETAINER, DRIVEN PULLEY
1
39$
9154
SCREW, HHC 3/8 - 16 X 1-3/4
4
40
+
20933
KIT, BEARING/SEAL HHN HELICAL ....................1 ................INCLUDES ITEMS W/ #
41
21854
GEARBOX ASSY., RIGHT ....................................1 ................INCLUDES ITEMS W/ $
42
21853
GEARBOX ASSY., LEFT.......................................1 ................INCLUDES ITEMS W/ $
43
21853854INPUT KIT, INPUT PINION/HUB/COUPLER ....................1 ................INCLUDES ITEMS W/ %
44
21853854INTER KIT, INTER PINION/GEAR ...................................1 ................INCLUDES ITEMS W/@
45
21853854OUTER KIT, OUTPUT SHAFT/GEAR ................................1 ................INCLUDES ITEMS W/ +
46
,
$
12687
KEY, 3/8 SQ X 2
1
