HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 65
twin pitCh assy. 1 (left/riGht)
NO. paRT NO. paRT Name qTy. RemaRKS
1+% 0126 B KEY, WOODRUFF #9 1
2+% 0161C WASHER, LOCK 5/16 MED 1
3@+% 0181 B WASHER, LOCK, 1/4 MED 4
4+% 0655 SCREW, HHC 5/16 – 18 X 3/4 1
5+% 0685 SCREW, SHS 5/16 – 18 X 5/16 1
6+% 0948 WASHER, FLAT, 1/4 SAE 1
7+% 10382 BOLT, SHOULDER, 3/8 X 3/8 LONG 1
8+ 10511 SHAFT, PITCH CONTROL, LH TPC ................. 1 .............. LEFT SIDE ONLY
9+% 10512 RING, SNAP, TRUARC 5160 – 75 1
10+% 10546 HOUSING, PITCH CONTROL, 1-3/4 1
11+ 10722 SLIDE BLOCK, LH PITCH CON ........................ 1 .............. LEFT SIDE ONLY
12+% 10723 PIN, SPIROL 3/16 X 1 3/8 HD 1
13+% 1116 NUT, BRASS JAM 5/16 – 18 2
14@+% 11583 U-JOINT, PITCH CONTROL 2
15@+% 1162 A CAP, GREASE ZERK 2
16+% 12460 CABLE, PITCH ASM 1
19+% 20005 SHAFT, TWIN PITCH 1
20@+% 11654 PIN, ROLL 1/8 X 1 PLATED ............................. 5 .............. QTY. INCLUDES USAGE ON BOTH TWIN PITCH
............................................................................................ ASSEMBLIES, AND MITER BOX SHAFTS
22+% 1529 GEAR, MASTER, TPC 1
23+% 1530 GEAR, SLAVE, TPC 1
24@+% 1578 KEY, WOODRUFF, #3 ........................................ 9 .............. QTY. INCLUDES USAGE ON BOTH TWIN PITCH
............................................................................................ ASSEMBLIES, AND MITER BOX SHAFTS
25+% 1579 SCREW, HHC 1/4 – 20 X 1/2 1
26+% 1586 PIN, ROLL 1/8 X 3/4 1
27+% 1604 BEARING, BALL 1
28+% 1612 BEARING, ALUM – PITCH CONTR 1
29@+% 1733 WASHER, 1/32 X 1/2 HARDENED 8
30+% 2007 SHAFT 1
33+% 2169 BEARING, THRUST, TORR #NTA 1220 1
34+% 2170 BEARING, RACE, TORR #TRA 1220 3
35+% 2311 SPACER, 3/4 X 1/2 X 0.8L 1
36+% 2367 SET COLLAR.NCLUDES ITEM 5
37+% 2620 SCREW, BHC 10 – 24 X 5/8 4
38@+% 2621 ZERK, GREASE STR 1/4 – 28 2
40+% 2649 COVER, PITCH CONT HOUSING 1
57 1617 LEVER ASSY, TROWEL ADJUSTMENT ........... 1 .............. INCLUDES ITEMS W/#
58 2300 DECAL, AL PITCH, RH 1
59 2332 DECAL, AL PITCH, LH 1
60# 4014 SCREW, 2-3/16 P-K TYPE U DRIVE 2
61#$ 4403 CRANK KNOB 1
62#$ 3231 SPACER 1
63# 1615 CRANK LEVER 1
64#$ 1733 HARDENED WASHER 1
65#$ 1616 SHOULDER BOLT 1
66# 0185 SCREW, SHSS 3/8 – 16 X 3/8" 1
67# 1528 SCREW, SHSS 1/4 – 20 X 5/16" 1
68% 10510 SHAFT, PITCH CONTROL, RH TPC ................. 1 .............. RIGHT SIDE ONLY
69% 10721 SLIDE BLOCK, RH PITCH CONTROL .............. 1 .............. RIGHT SIDE ONLY
70 10114 WASHER, EXT. SHKP, #8 4
71 1162A CAP, GREASE ZERK/2 1
72 2621 FITTING GREASE 1
73 2737 KNOB, KIT ......................................................... 1 .............. INCLUDES ITEMS W/$
NOTICE
Indicated quanties are for one pitch tower. If ordering for two pitch towers double the quantity.
