HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 79
enGine ClutCh assy. (new style)
NO. paRT NO. paRT Name qTy. RemaRKS
1 23377 SCREW, HHC 7/16-20 X 6.5 1
2 23369 WASHER, STEP 7/16 1
3 23363-1 CLUTCH, UPPER, MULTI-CLUTCH 1
4 23365 BELT, CVT CLUTCH 2
5 23368 STUB SHAFT 1
6 22021 SCREW, HEX FLANGE M8 5
7 22581 KIT, HHN CVT REPLACEMENT 1
8 23371 PULLER, MULTI-CLUTCH 1
NOTICE
Multi-Clutch components are not interchangeable with the prior Hoffco
Comet drive system. The Hoffco Comet CVT system must be replaced
with Multi-Clutch components in the event of a Hoffco Comet clutch failure.
