HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 49
suGGested spare parts
HHN31V RIDe-ON pOWeR TROWeL WITH
VaNguaRD Dm950 eNgINe
1 to 3 units
qty. p/N Description
4.............0189 ..................... HANDLE GRIP
4.............2267 ..................... HANDLE GRIP (RIGHT SIDE)
1.............11430 ................... SWITCH
2.............12460 ................... CABLE, PITCH
1.............1617 ..................... LEVER ASSY. TROWEL
............................................. ADJUSTMENT
2.............2737 ..................... KNOB ASSY.
1.............10208 ................... MUFFLER W/CLAMP
1.............10434 ................... CLAMP
1.............10463 ................... CLAMP
4.............10937 ................... BELT (B-37)
1.............11771 ................... BRACKET ENGINE THROTTLE
............................................. CABLE
1.............12168 ................... HEADER PIPE
1.............2124 ..................... THROTTLE CABLE
5.............2829 ..................... ARMS
2.............2124 ..................... CABLE THROTTLE (RT)
10...........10031 ................... WASHER 1/4 IN.
2.............11692 ................... BRACKET BATTERY
2.............11693 ................... BOLT BATTERY
6.............2509 ..................... WING NUT
2.............12548 ................... SPRAY PUMP
2.............2108 ..................... CAP SPRAY TANK
2.............10958 ................... SWITCH, IGNITION
1.............19301 ................... TERMINAL STRIP (10-POLE)
1.............2580 ..................... CHOKE CABLE
NOTICE
Part numbers on this Suggested Spare Parts list may
supersede/replace the part numbers shown in the
following parts lists.
qty. p/N Description
1.............2673 ..................... CIRCUIT BREAKER 30 AMP, 12V
2.............4682 ..................... TOGGLE SWITCH
2.............8381 ..................... BOOT, TOGGLE SWITCH
1.............11792 ................... ACCESSORY SOLENOID
4.............11078 ................... KEYS, IGNITION (SWITCH)
2.............2655 ..................... HOUR METER
2.............9005 ..................... LEVER TROWEL ARM (L.S.)
20...........0166A ................... WASHER
20...........1876 ..................... JAM NUT
20...........0164B ................... SCREW
5.............11039 ................... BUSHING
2.............9111 ..................... SPRING (L.S.)
20...........1875 ..................... WASHER
20...........1322 ..................... SCREW ASSY., ARM RETAINING
2.............12611 ................... SPIDER PLATE
20...........1162A ................... CAP GREASE FITTING
20...........16602 ................... SCREW (HHC 3/8 -16 X 3/8)
20...........1456 ..................... NUT (3/8 -16)
20...........12097 ................... SCREW (SQH 3/8-16 X 1 3/4
............................................. CONE)
2.............2143 ..................... SPRING (R.S.)
2.............1986 ..................... LEVER TROWEL ARM (R.S.)
2.............12005 ................... SAFETY KILL SWITCH
20...........0181B ................... WASHER 1/4 IN
2.............11418 ................... FUEL CAP/GUAGE
20...........4514 ..................... SCREW (HHC 1/4-20 X 5/8)
