HHN31VTCSL5 RIDe-ON TROWeL • OpeRaTION aND paRTS maNuaL — ReV. #8 (05/03/12) — page 67
twin pitCh assy. 2 (left/riGht)
NO. paRT NO. paRT Name qTy. RemaRKS
3@+% 0181 B WASHER, LOCK, 1/4 MED 4
14@+% 11583 U-JOINT, PITCH CONTROL 2
15@+% 1162 A CAP, GREASE ZERK 2
16+% 12460 CABLE, PITCH ASM 1
17 10548 TUBE, PITCH CONTROL W/A 1
20@+% 11654 PIN, ROLL 1/8 X 1 PLATED .............................5........... QTY. INCLUDES USAGE ON BOTH
....................................................................................... TWIN PITCH ASSEMBLIES, AND
....................................................................................... MITER BOX SHAFTS
21 1499 DECAL, WHITEMAN 1
22+% 1529 GEAR, MASTER, TPC 1
23+% 1530 GEAR, SLAVE, TPC 1
24@+% 1578 KEY, WOODRUFF, #3 .......................................9........... QTY. INCLUDES USAGE ON BOTH
....................................................................................... TWIN PITCHASSEMBLIES, AND
....................................................................................... MITER BOX SHAFTS
29@+% 1733 WASHER, 1/32 X 1/2 HARDENED 8
31 2012 SLEEVE, ADJ – LONG, RIDER 1
32 2156 SPRING, COIL 1
38@+% 2621 ZERK, GREASE STR 1/4 – 28 2
39 2634 DECAL, PITCH TOWER 1
41 0202 SCREW, HHC 5/16 – 18 X 1 4
42 0300 B WASHER, FLAT, 5/16 SAE 4
43@ 0730 SCREW, HHC 1/4 – 20 X 1 8
44@ 11653 SLEEVE W/U JOINT 1
45@ 1577 SET COLLAR, 1/2 2
46@ 1987 MITER BOX, PITCH CONTROL 1
47@ 1988 MITER BOX, BEARING CAP RIDERS 2
48@ 2021 SHAFT, MITER VERT 1
49@ 2022 SHAFT, MITER VERTICAL ...............................3........... QTY. INCLUDES USAGE ON BOTH
....................................................................................... TWIN PITCH ASSEMBLIES, AND
....................................................................................... MITER BOX SHAFTS
51@ 2845 SHAFT, MITER BOX HORIZ (HNN) 1
52@ 4514 SCREW, HHC 1/4 – 20 X 5/8 4
53 5283 NUT, NYLOC 5/16 – 18 4
56 11655 MITER BOX ASSY (HHN) ................................1........... INCLUDES ITEMS W/@
