MAYCO LS-40D/LS-40TD/LS-50TD PUMP — OPERATION AND PARTS MANUAL — REV. #11 (09/16/11) — PAGE 73
LS-40D/LS-40TD/LS-50TD
STRUCTURAL CONCRETE PUMP
1 Units
Qty. P/N Description
1 .......... EM16462 .............. FELT HOLDER
4 .......... EM98050 .............. PISTON CUP, ORANGE
4 .......... EM16493 .............. FELT RING
1 .......... EM98033 .............. OIL PLATE
2 .......... EM14408 .............. BRONZE RING
2 .......... EM16145 .............. BUSHING, SWING AXLE (BRONZE )
1 .......... EM98021 .............. WEAR PLATE
2 .......... EM16816-1A ........ ENERGIZER RING
1 .......... EM16816-2 ........... INSERT RING
2 .......... EM98065 .............. SLEEVE SEAL
1 .......... EM98022 .............. WEAR RING
1 .......... EM98065 .............. RUBBER RING
2 .......... EM14407 .............. O-RING
1 .......... 34507 ................... CAP, FUEL
2 .......... EM20763 .............. FILTER, FUEL (IN LINE)
1 .......... P53712 ................. CARTRIDGE, WATER SEPARATOR
3 .......... 01174416 ............. FILTER, OIL (ENGINE)
3 .......... 01174696 ............. FILTER, FUEL (ENGINE)
1 .......... EM98163 .............. SWITCH, PROXIMITY
MODELS LS-40D ONLY
Qty.
P/N Description
3 .......... 4384102 ............... CARTRIDGE, AIR FILTER
MODELS LS-40TD, LS-50TD ONLY
Qty.
P/N Description
3 .......... 1319257 ............... INSERT, AIR FILTER
3 .......... 1880870 ............... AIR CARTRIDGE, SAFETY
1 .......... EM981121 ............ ELEMENT, RETURN
LS-40D/LS-40TD/LS-50TD PUMP — SUGGESTED SPARE PARTS
LS-40D/LS-40TD/LS-50TD
STRUCTURAL CONCRETE PUMP
3 Units
Qty. P/N Description
1 .......... EM16459 .............. PIN
2 .......... EM25801 .............. CONCRETE CYLINDER
4 .......... EM16462 .............. FELT HOLDER
6 .......... EM98050 .............. PISTON CUP, ORANGE
8 .......... EM16493 .............. FELT RING
4 .......... EM98033 .............. OIL PLATE
4 .......... EM14408 .............. BRONZE RING
4 .......... EM16145A ............ BUSHING, SWING AXLE (BRONZE )
3 .......... EM98021A ............ WEAR PLATE
4 .......... EM16816-1A ........ ENERGIZER RING
2 .......... EM16816-2 ........... INSERT RING
4 .......... EM98065 .............. SLEEVE SEAL
6 .......... EM98022 .............. WEAR RING
3 .......... EM98065 .............. RUBBER RING
6 .......... EM14407 .............. O-RING
2 .......... EM16174 .............. O-RING
2 .......... EM98163 .............. SWITCH, PROXIMITY
6 .......... 510265 ................. BOLT, HEX HEAD 3/8 NC x 3-1/4 IN. G8
1 .......... 34507 ................... CAP, FUEL
6 .......... EM20763 .............. FILTER, FUEL
3 .......... P53712 ................. CARTRIDGE, WATER SEPERATOR
9 .......... 01174416 ............. FILTER, OIL (ENGINE)
9 .......... 01174696 ............. FILTER, FUEL (ENGINE)
MODELS LS-40D ONLY
Qty.
P/N Description
9 .......... 4384102 ............... CARTRIDGE, AIR FILTER
MODELS LS-40TD, LS-50TD ONLY
Qty.
P/N Description
9 .......... 1319257 ............... INSERT, AIR FILTER
9 .......... 1180870 ............... AIR CARTRIDGE, SAFETY
2 .......... EM981121 ............ ELEMENT, RETURN
Part numbers on this Suggested Spare Parts
List may supercede or replace the P/N shown
in the text pages of this book.
