MAYCO LS-40D/LS-40TD/LS-50TD PUMP — OPERATION AND PARTS MANUAL — REV. #11 (09/16/11) — PAGE 39
Safety chains must ALWAYS be used.
CAUTION - SAFETY CHAINS
8. Test the brakes by pulling the emergency stop lever
(Figure 39) forward until it locks into its second notch
position. Attempt to rotate the wheels in a forward
direction.
If any wheels rotate, the brakes must be adjusted. Return
the emergecny stop lever to its release position to adjust
the wheel brakes. Repeat step 8 as needed until brakes
prevent all wheel movement.
9. Cross the safety chains under the tongue and securely
attach them to the bumper or frame of the tow vehicle.
Check with local and state laws for proper compliance.
EMERGENCY BRAKE LEVER
RELEASE POSITION
Figure 39. Trailer Emergency Brake Lever
LS-40D/LS-40TD/LS-50TD — TOWING INFORMATION
10. Retract the jack fully. Remove and store the caster, if
applicable.
11. Check for proper truck-trailer hook-up; the tow vehicle
and trailer should be level with a positive tongue load.
For further information, consult a dealer or Atwood
Service Center.
CAUTION - SHARP TURNS WHILE TOWING
Avoid sharp turns. This could bend, create extreme
stress or fracture either the actuator or trailer tongue.
