page 4 — wm63-series mixer • operaTion and parTs manual — rev. #0 (09/27/12)
table Of cOntents
WM63H5/WM63H8/WM63e
plaster and Mortar Mixers
Proposition 65 Warning ........................................... 2
Silicosis/Respiratory Warnings ................................ 3
Table Of Contents .................................................... 4
Parts Ordering Procedures ...................................... 5
Safety Information .............................................. 6-10
Safety Chain Connection ....................................... 11
Specifications ........................................................ 12
Dimensions ............................................................ 13
General Information ............................................... 14
Components .......................................................... 15
Inspection ......................................................... 16-17
Basic Engine .......................................................... 18
Electric Motor ................................................... 19-20
Paddle Blade Adjustment ...................................... 21
Start-Up ............................................................ 22-23
Operation ............................................................... 24
Maintenance (Engine) ...................................... 26-27
Maintenance (Mixer) ......................................... 28-33
Troubleshooting ................................................ 34-36
Wiring Diagram ...................................................... 37
Explanation Of Code In Remarks Column............. 38
Suggested Spare Parts ......................................... 39
component drawings
Nameplate And Decals ..................................... 40-41
Frame Assembly ............................................... 42-43
Paddle Shaft Assembly ..................................... 44-45
Steel Tub Assembly .......................................... 46-47
Drum And Paddle Shaft Complete Assembly ... 48-49
Axle Assembly .................................................. 50-51
Engine Assembly .............................................. 52-53
Electric Motor Assembly ................................... 54-55
Cabinet Assembly ............................................. 56-57
Terms And Conditions Of Sale — Parts ................ 56
NOTICE
Specifications and part numbers are subject to change
without notice.
