page 14 — wm63-series mixer • operaTion and parTs manual — rev. #0 (09/27/12)
General infOrMatiOn
appliCaTion
The MQ Whiteman WM63 Series mixers (drum capacity
of 6.3 cu. ft./178 liters) are shipped completely assembled
and have been factory tested and are ready for use.
This mixer is only intended for the production of plaster and
mortar. The mixer must be used for its intended purpose
and is not suitable for the mixing of flammable or explosive
substances. The mixer must not be used in an explosive
atmosphere. This mixer has a batch capacity between 2-1/2
and 3-1/2 bags.
power planTs
The WM63 Series mixer can be equipped with either a
Honda GX160 or GX240 air-cooled, 4-stroke gasoline
engine. In addition this mixer is also available with a 1.5
HP electric motor with that can be configured for either
115 or 230 VAC operation by means of a voltage selector
switch. Refer to Table 2 for specific engine or electric motor
information.
eleCTriCal
If mixer is equipped with an electric motor, make sure that
the power being supplied to the motor corresponds to the
voltage rating label on the motor. Supplying the wrong
voltage to the electric motor will cause severe electrical
damage to the motor.
Always make sure the OFF/ON switch on the electric motor
is in the OFF position before applying power.
It is strongly recommended when inserting the mixer's
power cord into a receptacle, that a G.F.C.I. (Ground
Fault Current Interrupter) receptacle be used (115 VAC
applications).
Extension Cables
The extension cable should be a 3-wire configuration that
includes a ground wire that conforms to UL code. The wire
cross section must be a minimum of 2.5 mm 2 . Choose an
extension cord of adequate current carrying capacity as
referenced in Table 6. Remember cable distance affects
the current-voltage capacity of the extension cable.
Ensure that the extension cable is carefully laid out avoiding
wet areas, sharp edges and locations where vehicles might
run over it. Avoid allowing the extension cable to be trapped
underneath the mixer.
Unroll the extension cable fully or it will overheat and could
catch fire. Make sure that all extension cable connections
are dry and safe. Replace any defective or badly worn
extension cable immediately.
Hardware
Check all hardware on the mixer before starting. Periodically
inspect all hardware. Loose hardware can contribute
to early component failure and poor performance. Use
Table 4 as a general guideline when torqueing of mixer
hardware is required. Remember to keep all mixer hardware
components tight.
engine mainTenanCe
For basic engine maintenance, refer to the engine
maintenance section in this manual. For a more detailed
engine maintenance, refer to the Honda Engine Owner's
manual furnished with the engine.
Table 4. Hardware Torque recommendations
Hardware diameter Torque (ft-lbs)
5/16-inch x 18 14
3/8-inch x 16 24
3/8-inch x 24 37
1/2-inch x 13 39
1/2-inch x 13
(Grade 8)
90
