page 20 — wm63-series mixer • operaTion and parTs manual — rev. #0 (09/27/12)
The electric motor supplied is wired for 115 VAC grounded
operation. Make certain that the correct size grounded
(3-wires) extension cord is used. See Table 7 below.
Motors can burn out when the line voltage falls 10% below
the voltage rating of the motor. Failure to use proper voltage
will cause the motor to overheat and actuate the overload
switch.
If overload protection should actuate because of improper
voltage or any other malfunction, turn the main switch on
the motor to the "OFF" position and correct the problem,
press the reset switch button, and turn the main switch to
the "ON" position.
eleCTriC moTor volTage swiTCH
„ alwaYs make certain the electric motor switch is "OFF"
and the power cord has been disconnected from the
power source.
„ Remove the voltage lock-out bolt (Figure 12). Change
the position of the voltage change toggle switch from
115 VAC to 230 VAC. The mixer is factory wired for 115
VAC operation.
„ Replace the voltage lock-out bolt.
„ Important!, when changing the input voltage to the motor
from 115 to 230 VAC, the plug on the motor power cord
must also be changed. See Table 6
Table 7. recommended extension Cord sizes
Model Motor Voltage
50 ft.
(15.24 m)
75 ft.
(22.86 m)
100 ft.
(30.48 m)
200 ft.
(60.96 m)
WM63E 1.5 HP
115 VAC No. 12 No. 10 No. 8 No. 6
230 VAC No. 14 No. 12 No. 12 No. 8
electric MOtOr
