MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 63
NO PART NO PART NAME QTY. REMARKS
B 2846233200 CARBURETOR ASSY. ............................................... 1 ............... INCLUDES ITEMS W/ #
2 # 2846253908 LEVER SUB ASSY. THROTTLE 1
3 # 2846256008 COLLAR 1
4 # 2846231608 SPRING, THROTTLE 1
5 # 2516255908 BUSH 1
6 # 2846253308 SHAFT, THROTTLE 1
7 # 2846253508 THROTTLE VALVE 1
8 # 2846245508 SCREW 2
9 # 2846252908 LEVER CHOKE 1
10 # 2846252308 SHAFT CHOKE 1
11 # 2846252908 VALVE CHOKE 1
12 # 2846240108 MAIN JET #68 1
13 # 2846242008 SLOW JET 1
15 # 2516244908 SRING 2
16 # 2776258108 SCREW ADJUST 2
17 # 2846251508 PIN, FLOAT LEVER 1
18 # 2846250508 FLOAT ASSY. 1
19 # 2796250008 VALVE NEEDLE 1
20 # 2846254008 GASKET CHAMBER 1
21 # 2846255208 CHAMBER ASSY. FLOAT 1
22 # 2516266108 DRAIN SCREW 1
23 # 2846233508 SCREW 1
24 # 2516235008 GASKET 1
25 # 2846246508 NUT 2
26 # 2846246008 SPRING WASHER 2
27 # 2846245008 O-RING 1
28 # 2846245108 O-RING 1
29 # 2846256308 PLATE 2
30 # 2846245608 SCREW 1
31 # 2846246008 JET 1
32 # 2846243008 COLLAR 1
33 # 2516256508 RUBBER PIPE 1
40 # 2844550103 BUSH, THRO 1
ROBIN EH-092D ENGINE — CARBURETOR ASSY.
