MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 47
NO PART NO PART NAME QTY. REMARKS
10 2743170101 CAMSHAFT CP ............................ 1 ........ INCLUDES ITEMS W/%
34 2273860123 PIN (SPRING) 1
35% 2743640103 RELEASE LEVER 1
36% 0051904100 SPRING PIN 1
37% 0031517000 SNAP RING 1
38 2743870103 RETURN SPRING 1
50 2743330103 TAPPET 2
60 2743360103 VALVE SPRING 2
70 2743370103 SPRING RETAINER 2
80 2743340103 INTAKE VALVE 1
90 2743350103 EXHAUST VALVE 1
95 13210KA031 COLLET VALVE 4
210 2743530103 PUSH ROD 2
220 2743600103 ROCKER ARM 2
230 2693580103 BOLT (PIVOT) 2
240 0170060090 NUT 2
260 2743650103 GUIDE PLATE 1
310 2743010211 MUFFLER CP 1
330 2743700111 BRACKET CP (MUFFLER) 1
340 2743520101 GASKET CP (EXHAUST) 1
350 0176060020 SELF LOCK NUT 2
351 0023806000 FLANGE NUT ............................... 2 ........ REPLACES 0023806000
360 0110060010 BOLT AND WASHER ASSY. ........ 2 ........ REPLACES 0011406120
375 0011306120 FLANGE BOLT ............................. 2 ........ REPLACES 0110060010
510 2743260400 AIR CLEANER ASSY. ................... 1 ........ INCLUDES ITEMS W/ *
510-2 * 2303262008 GASKET 1
520 * 2743260307 ELEMENT SET 1
540 2303290103 INSULATOR 1
550 2303590103 GASKET (INSULATOR) 1
560 2303590203 GASKET 2 (INSULAT0R) 2
570 0176060020 SELF LOCK NUT 2
ROBIN EH-090D ENGINE — INTAKE AND EXHAUST ASSY.
