MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 31
CONTINUED
NO
PART NO PART NAME QTY. REMARKS
41 0031108000 WASHER 4
42 0310060020 DOWEL PIN 2
63 959006120 CLIP (TCP-10509B) 1
64 362341620 OIL GAUGE PROTECTOR 1
65 362341630 LINK PROTECTOR 1
66 002400820 BOLT 8X20 W/FLAT/LOCK WASHER 4
67 2741600113 STIFFENER 1
68 0011408250 BOLT AND WASHER 4
69 0011408300 BOLT AND WASHER ASSY. 2
71 362116871 AIR CLEANER ASSY. ........................................ 1 ........... INCLUDES ITEMS W/ #
71-1 # 362030011 COVER CP, AIR CLEANER 1
71-2 # 362030020 PACKING, AIR CLEANER 1
71-3 # 362030030 ELEMENT CP, AIR CLEANER 1
71-4 # 362030040 BOLT CP, AIR CLEANER 1
72 353342400 INTAKE PIPE 1
73 507010110 CLAMP TC-200 2
74 050300070 O-RING (7) 1
75 031108160 WASHER, FLAT M8 1
81 306010020 FRONT COVER 1
86 911210905 ENGINE ASSY., EH09D
CRANKCASE AND ENGINE ASSY.
