Multiquip MTR40F - Manual (Page 29)

MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 29
CLUTCH GUIDE / A 1
45 0053204201 WOODRUFF KEY 1
46 301010210 LOCK WASHER CLUTCH 1
47 956300130 THROTTLE LEVER AY 25 1
NO PART NO PART NAME QTY. REMARKS
1 305117260 CRANK CASE 1
2 305343780 CRANK GEAR 1
3 041006305 BEARING 6305Z 1
4 041006203 BEARING 6203Z 1
5 952401450 WASHER 8.5 x 22 x 3 1
6 001220825 BOLT 8 x 25 T 1
7 030208200 WASHER, LOCK M8 1
9 362455660 BEARING COVER 1
10 002210620 BOLT 6X20 H,SW 2
11 050100350 O-RING G-35 1
13 305333090 CONNECTING ROD 1
14 042006304 BEARING 6304ZZ 1
15 080100520 STOP RING R-52 1
16 952400130 WASHER 9304 1
17 001220825 BOLT 8 x 25 T 1
18 030208200 WASHER, LOCK M8 1
20 303010084 PINION 1
21 042006007 BEARING 6007ZZ 2
22 351437750 SPACER 35.4-42.7-11 1
23 080200350 STOP RING S-35 1
24 351421900 SPACER, CLUTCH DRUM 1
25 060504010 OIL SEAL VB-40525 1
26 050300900 O-RING S-90 1
27 362454441 CLUTCH ASSY. CE120P 1.6T ........................... 1 ........... INCLUDES ITEMS W/ *
27-1 * 943020020 CLUTCH SHOE C812 4
27-2 * 943050050 CLUTCH BOSS C812 1
27-3 * 943060100 CLUTCH GUIDE (A) 1
27-4 * 943060020 CLUTCH GUIDE (B) 1
27-5 * 943030021 CLUTCH SPRING 2
28 0053204201 WOODRUFF KEY 1
29 * 301010210 LOCK WASHER, CLUTCH 1
30 0173120010 LOCK NUT 1
32 362341610 PACKING, FRONT COVER 1
33 002200620 BOLT 6 x 20 H,SW 9
34 351010050 GREASE FITTING A-MT6X1 1
35 351010320 GREASE FITTING B-MT6X1 1
37 2741500123 ADAPTER FLANGE 1
38 0011408400 BOLT AND WASHER ASSY. 4
39 0021808000 NUT 4
40 0032008000 WASHER, LOCK 4
CRANKCASE AND ENGINE ASSY.
