MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 57
NO PART NO PART NAME QTY. REMARKS
10 2841010411 CRANKCASE CP .................................... 1 .......... INCLUDES ITEMS W/ #
20& 2371420203 VALVE GUIDE 2
26& 2771601001 STEM SEAL CP 1
30# 0440200070 OIL SEAL 20X32X6 1
40# 0600200110 BALL BEARING, 60074C3 1
50# 0310060020 DOWEL PIN 2
70 0105060430 STUD 2
75# 0440060020 OIL SEAL 1
80 0401140030 PLUG 1
90 0211140020 GASKET 1
150 2741600113 STIFFENER 1
160 0011408250 BOLT & WASHER 4
161 0011408300 BOLT & WASHER ASSY. 2
205 0241090060 GROMMET 1
210 2841100121 MAIN BEARING COVER ......................... 1 .......... INCLUDES ITEMS W/ *
220 * 0440200110 OIL SEAL 20X32X6 1
230 * 0600200110 BALL BEARING, 6004C3 1
250 2844500301 GOVERNOR GEAR CP 1
260 2054190103 GOVERNOR SLEEVE 1
265 * 0013908500 STUD 4
268 * 0310060020 DOWEL PIN 2
270 2306360101 OIL GAUGE ............................................. 1 .......... INCLUDES ITEMS W/ %
280% 0213160020 GASKET 1
300 0130060200 BOLT & WASHER 9
430 2741500123 ADAPTER FLANGE 1
437 0021808000 NUT 4
438 0032008000 SPRING WASHER 4
439 0031108000 WASHER 4
610 2841300110 CYLINDER HEAD ASSY. ........................ 1 .......... INCLUDES ITEMS W/ &
620 2841500113 GASKET HEAD 1
630 0110080210 FLANGE BOLT 1
631 0100080410 BOLT 2
680 2841550203 ROCKER COVER 1
685 2841450203 OIL SHELTER PLATE 1
690 2841600403 GASKET, ROCKER COVER 3
700 2771501103 PIPE KNOCK 2
710 0110060400 FLANGE BOLT 4
721 2841560203 BREATHER PLATE 1
722 2841600103 LEAF VALVE 1
723 2841600203 BREATHER PLATE 1
724 2841450103 OIL SHELTER PLATE 1
725 0131050020 SCREW & WASHER ASSY. 2
726 0131050020 SCREW & WASHER ASSY. 1
810 2841700103 COVER CASE 1
830 2301600613 GASKET TAPPET COVER NA 1
860 0011406160 BOLT & WASHER ASSY. 2
960 2849900117 GASKET SET 1
ROBIN EH-092D ENGINE — CRANKCASE ASSY.
