MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 33
NO PART NO PART NAME QTY. REMARKS
1 305446380 PISTON PIN 1
2 080100120 STOP RING R-12 2
3 305337980 PISTON ROD,M14 1
4 305451550 PISTON END, M14 1
6 305446400 STOPPER, UPPER 1
7 305446410 CYLINDER CAP 1
8 305446420 MAIN SPRING 2
9 305212710 SPRING CYLINDER 1
11 305112730 GUIDE CYLINDER 1
12 065105010 DUST SEAL DKI-5367811 1
13 080510680 STOP RING TH-R-68 1
14 351010050 GREASE FITTING A-MT6x1 2
15 305446430 STOPPER 1
16 001220816 BOLT 8x15 H, SW 4
18 305446440 GRIP 1
19 001520815 SOCKET HEAD BOLT 8x15 T 2
20 305446450 DUST SLEEVE 1
21 305446460 SLEEVE BAND 1
22 011208030 BOLT 8x30 1
23 020308060 NUT M8 1
25 050100800 O-RING G-80 1
26 002211025 BOLT 10x25 H, SW 4
GUIDE CYLINDER ASSY.
