MTR40F RAMMER — OPERATION AND PARTS MANUAL — REV. #3 (01/05/12) — PAGE 59
NO PART NO PART NAME QTY. REMARKS
10 2842030101 CRANKSHAFT CP 1
40 0230200100 SPACER T=0.8 1
41 0230200110 SPACER T=1.0 1
42 0230200120 SPACER T=1.2 1
50 0021814000 NUT 1
60 0032014000 SPRING WASHER .................................. 1 ..........REPLACES 0032012000
70 0053203101 WOODRUFF KEY 1
80 0053204201 WOODRUFF KEY 1
105 0173120010 LOCK NUT 1
310 2842250130 CONNECTING ROD ASSY. .................... 1 ..........INCLUDES ITEMS W/%
320% 2842300103 CONNECTING ROD BOLT 2
350 2302330103 PISTON PIN 1
360 28423401H3 PISTON 1
360 28423402H3 PISTON 0.25MM 1
360 28423403H3 PISTON 0.50MM 1
370 2842351107 PISTON RING SET 1
370 2842351207 PISTON RING SET 0.25MM 1
370 2842351307 PISTON RING SET 0.50MM 1
380 0565110010 CLIP 2
ROBIN EH-092D ENGINE — CRANKSHAFT AND PISTON ASSY.
