Insight Material Testing System
Specifications
Introduction 26
Specifications for MTS Insight 30 and MTS Insight 30 EL
Specifications MTS Insight 30 MTS Insight 30 EL
Force Capacity 30 kN (6750 lbf) 30 kN (6750 lbf)
Minimum Test Speed 0.001 mm/min. (0.00004 in./min.) 0.001 mm/min. (0.00004 in./min.)
Maximum Test Speed 500 mm/min. (19.7 in./min.) 500 mm/min. (19.7 in./min.)
Force Capacity
@ max. test speed 25 kN (5625 lbf) 25 kN (5625 lbf)
Maximum Test Speed
@rated force capacity 500 mm/min. (19.7 in./min.) 500 mm/min. (19.7 in./min.)
Crosshead Return Speed 500 mm/min. (20 in./min.) 500 mm/min. (20 in./min.)
Vertical Test Space
(crosshead travel) 1100 mm (43 in.) 1400 mm (55 in.)
Horizontal Test Space
(space between columns) 405 mm (15.9 in.) 405 mm (15.9 in.)
Position Resolution 0.001 mm (0.00004 in.) 0.001 mm (0.00004 in.)
Position Accuracy 0.01 mm (0.0004 in.) 0.01 mm (0.0004 in.)
Speed Accuracy % of set speed ± 0.05 ± 0.05
Motor Type Precision DC Servo Motor Precision DC Servo Motor
Drive System Type DC 4 Quadrant Motor Drive DC 4 Quadrant Motor Drive
Position Measurement Optical Encoder Optical Encoder
Ball Screw Type Anti-backlash Anti-backlash
Guide Columns Two Two
Height/Width/Depth 1619 X 720 X 500 mm
(63.7 X 28.3 X 19.7 in.) 1913 X 720 X 500 mm
(75.4 X 29 X 20 in.)
Weight 180 kg (397 lb) 191 kg (422 lb)
Power 5/3 Amps
120/220-240 Vac
50/60 Hz
Single phase 5/3 Amps
120/220-240 Vac
50/60 Hz
Single phase
