Insight Material Testing System
Specifications
Introduction 22
Specifications for MTS Insight 2 and MTS Insight 2 EL
Specifications MTS Insight 2 MTS Insight 2 EL
Force Capacity 2 kN (450 lbf) 2 kN (450 lbf)
Minimum Test Speed 0.001 mm/min. (0.00004 in./min.) 0.001 mm/min. (0.00004 in./min.)
Maximum Test Speed 1000 mm/min. (39.4 in./min.) 1000 mm/min. (39.4 in./min.)
Force Capacity
@ max. test speed 2 kN (450 lbf) 2 kN (450 lbf)
Maximum Test Speed
@rated force capacity 1000 mm/min. (39.4 in./min.) 1000 mm/min. (39.4 in./min.)
Crosshead Return Speed 1500 mm/min. (59 in./min.) 1500 mm/min. (59 in./min.)
Vertical Test Space
(crosshead travel) 750 mm (29.5 in.) 1000 mm (39.5 in.)
Horizontal Test Space
(centerline to rear column) 104 mm (4.1 in.) 104 mm (4.1 in.)
Position Resolution 0.001 mm (0.00004 in.) 0.001 mm (0.00004 in.)
Position Accuracy 0.01 mm (0.0004 in.) 0.01 mm (0.0004 in.)
Speed Accuracy % of set speed ± 0.05 ± 0.05
Motor Type Precision DC Servo Motor Precision DC Servo Motor
Drive System Type DC 4 Quadrant Motor Drive DC 4 Quadrant Motor Drive
Position Measurement Optical Encoder Optical Encoder
Ball Screw Type Anti-backlash Anti-backlash
Height/Width/Depth 1136 X 490 X 450 mm
(45 X 19 X 18 in.) 1394 X 490 X 450 mm
(55 X 19 X 18 in.)
Weight 50 kg (110 lb) 55 kg (119 lb)
Power 5/3 Amps
120/220-240 Vac
50/60 Hz
Single phase 5/3 Amps
120/220-240 Vac
50/60 Hz
Single phase
