Series 311 Load Frame
Installation
33
Installation
This section describes how to install the Series 311 Load Frame.
Contents
Removing the Shipping Collars 40
Prerequisite
You will need a fork lift or overhead crane capable of lifting the load frame.
Ensure the lifting equipment can accommodate the weight of the load frame, see
the following table.
Procedure
Perform the following to install the load frame.
1. Unpack the load frame. Go to
unpack and move the load frame.
2. Connect the cables between the load frame and controller. Go to
on page 38 to make the various controller connections.
Return to this procedure when done.
3. Connect the hydraulic hoses between the load frame and hydraulic service
manifold. Go to
on page 39 to connect the load
frame to your hydraulic supply system. Return to this procedure when done.
4. Remove the collars on the columns so the load frame can be used. Go to
“Removing the Shipping Collars”
on page 40 to complete the installation
procedure.
Series 311 Load Fame Weights
Model
Weight
311.11
900 kg (2000 lb)
311.21
2000 kg (4500 lb)
311.31
3500 kg (8000 lb)
311.41
8500 kg (19,000 lb)
311.51
16,000 kg (36,000 lb)
311.61
27,000 kg (60,000 lb)
311.71
36,000 kg (80,000 lb)
