Specifications
Series 311 Load Frame Introduction 19
Specifications
This section provides some of the specifications of the Series 311 Load Frame.
Other specifications can be found on the assembly drawings specific to each load
frame.
Parameter Specification
Force rating
311.11
311.21
311.31
311.41
311.51
311.61
311.71 250 kN (55 kip)
500 kN (110 kip)
1000 kN (220 kip)
2500 kN (550 kip)
5000 kN (1100 kip)
7500 kN (1650 kip)
10,000 kN (2200 kip)
Crosshead weight
311.11
311.21
311.31
311.41
311.51
311.61
311.71
approximate weight
180 kg (400 lb)
320 kg (700 lb)
680 kg (1500 lb)
1680 kg (3700 lb)
3175 kg (7000 lb)
5450 kg (12,000 lb)
7300 kg (16,000 lb)
Total weight
*
311.11
311.21
311.31
311.41
311.51
311.61
311.71
* The weight specification is for lifting and moving purposes. The weight
includes a typical actuator, force transducer, and grips. The actual
shipping weight must be determined by a scale.
approximate weight
900 kg (2000 lb)
2000 kg (4500 lb)
3500 kg (8000 lb)
8500 kg (19,000 lb)
16,000 kg (36,000 lb)
27,000 kg (60,000 lb)
36,000 kg (80,000 lb)
