Model 512.04 Hydraulic Power Unit
32
Maintenance
Component Locations
Synasol is toxic and flammable.
Use the Synasol solvent in a ventilated area and keep it away from an open
flame.
Follow the cautions and warnings on its container.
Reservoir
Cover Screws
Stop Switch
Filler Cap
Pump Filter
Drain
Hydraulic Fluid
Hoses (to the
heat exchanger)
