Model 512.04 Hydraulic Power Unit

14

Installation

2.

Connect the hydraulic lines.

See

“Connection Locations”

on page 13 to determine the locations of

the hydraulic connections to the HPU. See the following table to
identify the size of each hydraulic connection.

3.

Connect the water lines to the heat exchanger.

NOTE

This only applies to the water-cooled version of the HPU.

See

“Connection Locations”

on page 13 to determine the locations of

the water connections.

4.

Connect an external Emergency Stop switch.

An optional

Emergency Stop

switch can be connected to the 14–pin

CPC connector located on the control box. Before you can use this
connector, remove the jumper from pins 1 and 3 located on the
terminal block in the control box (see

“Electrical Schematic”

on page

15).

5.

Connect the electrical service to the HPU.

NOTE

You may want to have an electrician complete this step. Also, local
electrical codes supersede any information found here.

A.

Open the control box.

B.

Open a knock-out hole.

C.

Install a wire grommet.

D.

Feed the line through the grommet into the control box.

E.

Connect the power source lines (L1–L3) to the terminal blocks
according to the required line voltage. See

“Electrical Schematic”

on page 15.

F.

Connect the ground to the lug identified with a sticker showing
the ground symbol.

Hydraulic Connectors

C

ONNECTOR

S

IZE

Pressure, 37º flare

-8

Return, 37º flare

-8

Drain, 37º flare

-6
