Page 20
Series FEC Environmental Chamber Product Manual
20
Installing Bracket of Environmental Chamber
Installation
Installing Bracket of Environmental Chamber
Environmental chambers are installed onto different brackets that are composed
extruded aluminum and consist of front guide bracket and rear guide bracket.
During high and low temperature test, front and rear guide bracket are connected
and fixed onto testing machine.
Back Door of Enclosure
Crosshead
Environmental
Chamber
Front Door of
Enclosure
Front Guide
Bracket
Rear Guide
Bracket
