Series FEC Environmental Chamber Product Manual 16
Specifications
Introduction
Specifications
The section provides operating condition requirements and detailed specification
of the environmental chambers.
Operating Condition Requirements
Use the environmental chambers under the following conditions:
Model and Specifications
P ARAMETER S PECIFICATION
Condition For indoor application only
Ambient temperature of cabinet 5 ~ 40 ° C (41 ~ 104 °F )
Relative humidity 5-85%, noncondensing
Maximum altitude 2000 m (6562 ft)
Voltage Single-phase AC 200 ~ 240 V ± 10%
Frequency 50 Hz / 60 Hz
Current 15 Amps
M ODEL FEC1200 FEC1300
Scope of application C43.104, C43.104E, C43.304,
C43.304E, C43.504, C43.504E,
C44.104, C44.104E, C44.304,
C44.304E C45.504, C45.105
C45.504E, C45.105E
Temperature scope -70 ~ 350 ° C (- 94 ~ 662 °F ) -70 ~ 350 ° C (- 94 ~ 662 °F )
External dimension (W × D × H) 360 Ч 1060 Ч 795 mm
(14.2 Ч 41.7 Ч 31.3 in) 460 Ч 1060 Ч 800 mm
(18.1 Ч 41.7Ч 31.5 in)
Dimension of test space
(W × D × H) 200 Ч 200 Ч 600 mm
(7.9 Ч 9.4 Ч 23.6 in) 300 Ч 200 Ч 600 mm
(11.8 Ч 9.4Ч 23.6 in)
Temperature fluctuation ≤ ±1 ° C ≤ ±1 ° C
Temperature deviation ≤ ±2 ° C ≤ ±2 ° C
Temperature uniformity ≤ ±2 ° C ≤ ±2 ° C
Heatup time ≥ 5 ° C/min ≥ 5 ° C/min
Cooling time ≥ 2 ° C/min ≥ 2 ° C/min
Heatup time (room
temperature~350
°
C)
≤ 60 min ≤ 60 min
Weight 105 kg 120 kg
