PRODUCT OVERVIEW AND ASSEMBLY

eng

11

4. Rotate the cam lock clockwise 180°. Move the cam lock flush

against the top housing.

180°

39062

5. To secure the handle, hold the handle steady while rotating and

tightening the cam lock clockwise 180°. Verify that the flat surfaces

of the handle, cam lock, and top housing are in alignment.

a -

Top housing

b -

Cam lock

c -

Handle

a

b

c

45694
