16" Coverage
8"
1 5 /
8
"
C
Barb
(12"o.c.)
1. Theoretical section properties have been calculated per AISI 2001 “Specification for the Design of Cold-formed Steel Structural Members.” Ixx and Sxx are
effective section properties for deflection and bending.
2. Allowable load is calculated in accordance with AISI 2001 specifications considering bending, shear, combined bending and shear, deflection, and applicable
testing when available. Allowable load considers the worst case of 3 and 4 equal span conditions. Allowable load does not address web crippling or
fasteners/support connection and panel weight is not considered.
3. Deflection consideration is limited by a maximum deflection ratio of L/180 of span.
4. Allowable loads do not include a 1/3 stress increase in uplift.
ALLOWABLE UNIFORM LOADS PSF
(3 or More Equal Spans)
2.5' 3' 3.5' 4' 4.5' 5' 2.5' 3' 3.5' 4' 4.5' 5'
SECTION PROPERTIES
Bottom in Compression
Width
(in.)
Yield
KSI
16" 50
16" 50
16" 50
26
Ga.
24
22
Sxx
In 3 /ft
Ixx
In 4 /ft
Weight
PSF
0.99
1.30
1.69
Top in Compression
Sxx
In 3 /ft
Ixx
In 4 /ft
Inward
Load
Outward
Load
0.0905 0.0748 0.0466 0.0566 175 128 97 76 61 50 45 42 40 37 35 32
0.1178 0.0979 0.0638 0.0756 231 169 129 101 81 67 66 59 51 44 37 29
0.1515 0.1264 0.0870 0.1001 302 222 169 133 107 88 109 107 105 103 101 99
 Slope
 Substructure
 Clips
 Coverage
 Length
 Fasteners
 Availability
GENERAL INFORMATION ATTACHMENT DETAIL
PANEL CLIP
The minimum recommended slope for the Clip-Loc roof
panel is 1:12.
Clip-Loc is designed to be utilized over open structural
framing or a solid substrate.
Clip spacing is based upon the spacing of structural framing
members and loading requirements.
Clip-Loc panels are available in a 1 5 /
8
" seam height with a
16" width coverage.
Minimum factory cut length is 5'-0". Maximum
recommended panel length is 45'-0". Longer panels
require additional consideration in packaging, shipping, and
erection. Please consult Metal Sales for recommendations.
The fastener selection guide should be consulted for
choosing the proper fastener for specific applications.
Quantity and type of fastener must meet necessary loading
and code requirements.
NOTE: All panels are subject to surface distortion due to
improperly applied fasteners. Overdriven fasteners will
cause stress and induce oil canning across the face of the
panel at or near the point of attachment.
Finishes: Acrylic Coated Galvalume ® , or various Kynar 500
(PVDF) colors.
Gauges: 26ga, 24ga, and 22ga
Clip
Clip-Loc Panel
Clip-Loc Clip
Tape Sealant (Slopes Less Than 3:12)
