PCL-16
CLIP-LOC
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
CliP-loC
r
ake
P
araPeT
(o
n
m
odUle
) d
eTail
Double Bead Tape Sealant
# 1 /
4
-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
Clip-Loc Panel
Floating Rake Zee
Clip-Loc Rakewall
#12-14 x 1 1 /
4
" Shoulder Tech (1'-0" o.c.)
1:12 Slope
Minimum
r
ake
P
araPeT
(o
ff
m
odUle
) d
eTail
Double Bead Tape Sealant
# 1 /
4
-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
Clip-Loc Panel
Floating Rake Zee
Clip-Loc Rakewall
#12-14 x 1 1 /
4
" Shoulder Tech (1'-0" o.c.)
#12-14 x 1 1 /
4
" SD XL (1'-0" o.c.)
1:12 Slope
Minimum
 Field bend panel rib up 1 5 /
8
"
