Metal Sales Clip-Loc Manual - Manual (Page 20)

PCL-20
CLIP-LOC
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
v
enTed
r
idge
d
eTail
Double Bead Tape Sealant
#
1 /
4
-14 x 7 /
8
" Stitch XL (8"o.c.)
Perforated Vent Drip
Clip-Loc Clip
Clip-Loc Outside Closure
13" Step Ridge
Clip-Loc Panel
# 1 /
4
-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
CL
Double Bead Tape Sealant
1:12 Slope
Minimum
CliP-loC h
ighside
P
araPeT
d
eTail
Double Bead Tape Sealant
# 1 /
4
-14 x 7 /
8
" Stitch XL (8"o.c.)
Clip-Loc Panel
Clip-Loc Clip
Clip-Loc Outside Closure
SSR Pitch Break
Double Bead Tape Sealant
2"
Max.
12"
Max.
1:12 Slope
Minimum
h
ighside
P
araPeT
(o
PTional
) d
eTail
2"
