PCL-17
CLIP-LOC
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
v
alley
d
eTail
Double Bead Tape Sealant
Clip-Loc Inside Valley Closure
Clip-Loc Panel
Clip-Loc Clip
Valley Plate
Valley
6" Minimum
#12-14 x 1 1 /
2
" SD XL (optional)
(6 per panel - see below)
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
 Clip-Loc panel must be anchored to open framing behind outside
closure at all ridge, endwall, and peak conditions to fix the panel
when using this floating eave detail.
1:12 Slope
Minimum
Clip-Loc Fastening Pattern
#12-14 x 1 1 /
4
" SD XL
(6 per panel)
