D24022 | Date 10/2014 35
Menu functions
All other settings can be made accordingly. The settings possible are described in the follow-
ing sections.
If no new values are entered or confirmed for approx. 30 seconds, the appliance automati-
cally returns to the main menu and restores the former values.
7.3 Setup
In the SETUP display, you can set the following parameters:
►
the IP address and Subnet mask of the appliance's Ethernet interface (for connection to Subnet mask Subnet mask
a network)
►
the Unit of the temperature display (°C or °F, see page 36)
►
the type of temperature monitoring (TWW or TWB, Alarm Temp, only if equipped with
a second temperature sensor, option A6) and the trigger temperature of the monitoring
function ( Max alarm , see page 37)
►
how the digital backwards counter with target time setting works ( Timer mode , see page
38)
►
the type of the slide-in unit (Grid or Shelf, see page 38)
►
Remote control (see page 38)
►
Gateway (see page 39)
If the SETUP menu contains more entries than can be
displayed, this is indicated by the display “1/2”. This
means that there is a second „page“ of entries.
To display the hidden entries, use the turn control
to scroll beyond the lowest entry. The page display
changes to “2/2”.
7.3.1 IP address and subnet mask
If you want to operate one ore more appliances in a network, each appliance must have its
own unique IP address for identification. By default, each appliance is delivered with the IP
address 192.168.100.100.
LAN 1: 192.168.1.233
192.168.1.216
LAN 2: 192.168.1.215 LAN 3: 192.168.1.241
Editor Programmname Simulation Protokoll
- + - +
Test 01 180.0°C i
HPP 250 Labor
i 37.0°C 44.4%rh
STAND BY
Programm n e g n u l l e t s n i E l l o k o t o r P t ä r e G e f l i H n e k c u r D AtmoCONTROL
Fig. 21 Operation of several appliances in a network (schematic example)
Setup
Unit
IP adress 255.145.136.225
Subnet mask 255.255.0.0
Alarm Temp
°C F
Timer mode
TWW TWB
1/2
