Page 40
Item Qty. Description RA500-3236
REPAIR PARTS
Weldment, Ramp Frame - RA500 RA0W
2 Linear Guide System - Rail MOD RA0020M
3 3 Linear Guide System - Carriage RA002
4 Switch, Rear Stop - RA500 RA0022
5 Sprocket, Fixed Guide - Manual Release - ER0 2749
6 Bearing, Plain Plastic - ID 8MM / OD 0MM - ER 27497
7 Weldment, Traveling Cross Arm - RA500 RA02W
8 Weldment, Chain End - RA500 RA0024W
9 7 Nut, M5 Nylock ZP 83038
0 3 Skid Pad, RA500 RA0026
Roller, Carriage - RA500 RA0028
2 3 Microswitch, Sealed 30205
3 Top Plate, Alum w/ or w/o Laminate RA023
4 Hinge, SS 2" x /4" x 30" or 40" 869R030
5 Threshold, RA500 RA022Y
6 Track Cover, Left - RA500 RA003Y
7 Track Cover, Right - RA500 RA0032Y
8 Bottom Panel - RA500 RA024
9 Access Panel - RA500 RA0034
20 4 Screw, M5 x 0 Flat Socket Head Cap - SS 27448
2 23 Screw, M5 x 23 Flat Socket Head Cap - SS 27453
22 Motor, GR63 x 55 w/PLG52 28:RDU - 24V RA0080A
23 Miter Gear Set, .5M 6/32 Tooth - Bev Gear RA008M
24 Motor Support - RA500 RA0083
25 Pivot Pin - RA500 RA0084
26 2 Stainless Rod, 3/8" Dia. #303 x 2.5" or 3" 80379R02.5
27 Release Cam - RA500 RA0090
28 Steel Bar - 3/6" Sq. x 7/8" 28R000.875
29 2 Bearing, Flange - 8MM x 7.7MM 32400
30 20 Screw, M4 x 6 - FHSCS/SS 32399
3 2 E Clip, 5/6" Shaft - /4" Groove 84086
32 22 Screw, M4 x 0 - BHSCS/SS 3053
33 - - -
34 9 Screw, M5 x 0 Button Head Socket Cap - SS 28786
35 Motor Mount - RA500 RA0089
36 Washer, .328" x .562" x .042" - SS 83583
37 2 Spring, 0.72" OD / .096" WD / .5L / Compr - SS RA004
38 3 Screw, M5 x 5MM Set 832
39 8 Rivet, M4 x 0 Countersunk Blind 2744
40 6 Screw, M6 x 6 Flat Head Socket Cap - SS 27758
4 8 Screw, M4 x 0 Flat Head Socket Cap - SS 27440
42 4 Screw, M3 x 0 Flat Head Socket Cap - SS 27438
43 2 Plate, Tapped #4-40 Microswitch 24998
44 6 Screw, Mach. #4-40 x 5/8" Rd Hd - Auto BK 480
45 23 Nut, Weld - M5 Plain Slab Base 32402
46 Screw, M5 x 20 Hex Head Cap - SS 27452
47 Chain, Roller 8MM Pitch - Procoat x 99" 28532R099
48 4 Bearing, Plastic - Flange 3/8" ID x /4" 24028
49 Cable, Manual Release - M8 x 450 x79-ER0 27526
50 Assembly, Platform - Weight Sensing - RA323 RA00A
5 4 Tape, Adhesive - UHMW Film - .020" x 3" - Blk 28475R
52 Weldment, Hinge 2" x /4" x 32" or 4" - SS 869W032Y
53 Weldment, Sprocket - Drive Position - Carriage RA026W
54 Top Cover, Mat RA03
55 2 Link, Chain Master - 8mm Pitch - SS 27428
56 Harness, Ramp RA0060A
57 Assembly, RA500 Interface Board 0028-00
58 2 Grip Tape, Traction Adhesive 3" x 2" - Yellow or Black 2473-YL
59 Harness, Ramp Controller RA028A
60 2 Tag, Serial # / Series # - Plastic 8548P
6 Assembly, Platform - Weight Sensitive RA00A
62 Assembly, Controller RA500 Interface Board 0028-00
*
Item not Shown
*
*
*
*
*
*
*
*
*
*
*
*
*
*
