Perform all procedures listed in previous section also

1 Year

1250

Cycles

continued

8 Weeks

or 200

Cycles

MAINTENANCE and LUBRICATION

Repeat all previously listed inspection, lubrica-

tion and maintenance procedures at 8 week or

200 cycle intervals (or per vehicle maintenance

schedule).

Consecutive

8 Week or

200 Cycle

Intervals

Clean and lubricate. Apply Door-Ease

Clean and remove debris or obstructions

Correct as needed

Blow out with air compressor

Re secure, replace defective parts or otherwise

correct as needed.

Apply Grease - See Lubrication Diagram

Apply Light Oil - See Lubrication Diagram

Adjust as needed

Re secure, repair or replace or otherwise cor-

rect as needed

Check to see that the ramp is securely an-

chored to the vehicle and there are no loose

bolts, broken welds, or stress fractures.

Replace decals if worn, missing or illegible.

Replace antiskid if worn or missing.

Carrier plate wear strips

Clean ramp and ramp mounting area (ensure

no debris in area to obstruct stowing )

Inspect ramp for wear, damage or any abnor-

mal condition.

Remove motor cover and clean dirt and other

foreign debris

Remove motor cover and inspect:

• Harness cables, wires, terminals and con-

nections for securement or damage

Drive gear

Motor guide rails

Manual release CAM

Drive chain

Adjust chain tension

Inspect vehicle-to-ramp wiring harness

Mounting

Antiskid

Maintenance and Lubrication Schedule (continued)
