RAMP INSTALLATION
Door(s) must
open outward.
Chassis
Chassis
Chassis
Chassis
Chassis
Chassis
CL
Minimum Door Opening W
idth:
850mm opening
for 825mm Ramp
CL
MINIMUM
DOOR OPENING
WIDTH
Chassis
Chassis
Chassis
Chassis
SUPPORT TUBE
1455mm
1005mm
SUPPORT TUBE
Installed Ramp - Stowed RA500 w/o Fixed Sub floor
Figure N
The movable ramp
platform must be
aligned with the
center of the door
opening.
