Page 22
Installed Ramp - Stowed
Stowed RA500
Ramp positioned in
the “floor pocket.”
As viewed from outside the vehicle
Left
Right
Rear
Front
Outboard
(passenger's side)
Inboard
(driver's side)
“Arrows/30°-30°”6-13-90
(of vehicle)
(of vehicle)
Out
In
Chassis
Chassis
Chassis
Chassis
Chassis
Chassis
Chassis
Chassis
CL
Minimum Door Opening W
idth:
850mm openin
g
for 825mm Ramp
CL
MINIMUM
DOOR OPENING WIDTH
SUPPORT TUBE
1455mm
1005mm
Floor Pocket
Frame W
ork
RAMP INSTALLATION
Figure J
