1005mm, 1455mm, Ramp installation – Braun RA500 User Manual

Page 22

Page 20

Chassis

Minimum Door Opening W

idth:

850mm openin

for 825mm Ramp

MINIMUM

DOOR OPENING

WIDTH

SUPPORT TUBE

1455mm

1005mm

Floor Pocket

Frame W

ork

"Floor Pocket" Clear Opening Dimensions

As viewed from outside the vehicle

Left

Right

Rear

Front

Outboard

(passenger's side)

Inboard

(driver's side)

“Arrows/30°-30°”6-13-90

(of vehicle)

Out

RAMP INSTALLATION

Figure G

The ramp must

be supported by a

minimum of three

chasis members.
