1005mm, 1455mm, Ramp installation – Braun RA500 User Manual

Page 29: Figure p

Page 27

Installed Ramp - Stowed with Vehicle Floor Installed over Ramp

As viewed from outside the vehicle

Left

Right

Rear

Front

Outboard

(passenger's side)

Inboard

(driver's side)

“Arrows/30°-30°”6-13-90

(of vehicle)

Out

Chassis

Minimum Door Opening W

idth:

850mm opening

for 825mm Ramp

MINIMUM

DOOR OPENING

WIDTH

Chassis

SUPPORT TUBE

1455mm

1005mm

SUPPORT TUBE

RAMP INSTALLATION

Figure P

Floor should support

upper surface of the

ramp.
