4 Electrical installation
LON connection
EDKMF2141 DE/EN/FR 2.0 35
L
Designation Explanation -17-
FTT / Connection for LON bus, two cores (twisted pair)
Connection terminals
Electrical connection Plug connector with threaded terminal end
Possible connections rigid: 1.5 mm 2 (AWG 16)
flexible:
without wire crimp cap
1.5 mm
2 (AWG 16)
with wire crimp cap, without plastic sleeve
1.5 mm
2 (AWG 16)
with wire crimp cap, with plastic sleeve
1.5 mm
2 (AWG 16)
Tightening torque 0.5 ... 0.6 Nm (4.4 ... 5.3 lb-in)
Bare end 6 mm
