Lenze EMF2141IB 2141 LON User Manual
Page 24
EDKMF2141 DE/EN/FR 2.0
24
L
Legend for fold-out page
1
Status display (green) for voltage supply
2
Status display (yellow) for LON communication
^ 40
3
Status display (red / green) for the device
^ 40
4
Service LED
5
Service key
^ 37
6
PE shield cable connection
7
Fixing screw
8
Plug connector, connection for external voltage supply
^ 33
9
Plug connector, LON connection
^ 35
:
Nameplate
^ 25
