Safety option 30
Error management
Module error messages
5
l
60 EDS84DPSO01 EN 2.1
Error type/response/
Note Description Range Error type/response/
Note Description
Error number
Test functions − inputs
144 0x90 Stuck at High SD−In1, channel A
(Short circuit (High)
Trouble/−
SD−In1: OFF state
145 0x91 Stuck at High SD−In1, channel B
146 0x92 Stuck at High SD−In2, channel A Trouble/−
SD−In2: OFF state
147 0x93 Stuck at High SD−In2, channel B
154 0x9A CLA/CLB short circuit
Short circuit between the CLA and CLB clock outputs Trouble/−
SD−In: OFF state
Safe parameterisation
160 0xA0 New parameter set deleted
(by the safe parameter setting in the Engineer)
−/−
Logbook entry: Info
161 0xA1 New safe parameter set loaded
(by the safe parameter setting in the Engineer or the procedure
with the module switch)
162 0xA2 Memory module parameter set − access error
(Error while accessing the parameter set of the memory module.)
Trouble/STO
OFF state for all SD−In
163 0xA3 Different parameter sets
(within the memory module and the drive−based safety)
164 0xA4 No safe parameter set in the drive−based safety
(drive−based safety does not have a parameter set)
165 0xA5 Defective SM301 parameter set
(parameter set of the drive−based safety is defective)
166 0xA6 Parameter set in memory module − format error
(Format error in parameter set of memory module)
167 0xA7 Parameter set − plausibility error
168 0xA8 Parameter set − communication error
(Communication error when loading the parameter set)
169 0xA9 Module ID does not equal effective safety address
(Module ID in the parameter set does not equal the effective
safety address) Warning/STO
OFF state for all SD−In
Test functions − internal module
192 0xC0 Reference voltage error
Trouble/STO
OFF state for all SD−In
193 0xC1 6 V voltage error
194 0xC2 5 V voltage error
195 0xC3 2.6 V voltage error
Tab. 5−2 Description of the numerical entries
