Safety option 30

Electrical installation

5

l

41

EDS84DPSO01 EN 2.1

5.4

Electrical installation

Principle circuit diagram

S3

S1

S4

1

CLA

2

3

4

5

6

7

8

CLB

GND-CLK

I2A

GND-I2

I2B

GND-CLK

GND-I2

X64

1

CLA

2

3

4

5

6

7

8

CLB

GND-CLK

I1A

GND-I1

I1B

GND-CLK

GND-I1

X63

1

AIE

2

3

4

5

24_ACK

AIS

GND-SM

GND-SM

X62

E84Dx...-x xxS

L

84DPSSO031

E84DxWT...

8400 protec controller with safety option 30

S1

Passive sensor with channel A and B (at X64 in our example)

S3

Higher−level safety control (active sensor)

S4

Lightgrid (active sensor) (at X63 in our example)
