Lenze SO30 8400 protec - Manual (Page 42)

Safety option 30
Electrical installation
5
l
42 EDS84DPSO01 EN 2.1
Terminal assignment
}
Danger!
Danger to life through improper installation
Improper installation of the safety engineering systems can cause
anuncontrolled starting action of the drives.
Possible consequences:
ƒ Death or severe injuries
Protective measures:
ƒ The installation of the cables between X62, X63, and X64 and the connected
components must be shielded:
– Attach the shield at least in the connector shell.
– Also attach the shield to the connected component if possible.
X62 − connection of safety engineering system "Safety Option 30"
Pin Connection Description Data
M12, 5−pole sockets, A−coded
84DPSO05_5
1 AIE Error acknowledgement
2 24_ACK 24−V supply voltage for reset button max. 300 mA
3 AIS Restart acknowledgement
4 GND_SM
GND potential
5 GND_SM
