Safety option 30
Technical data
5
l
40 EDS84DPSO01 EN 2.1
5.3 Technical data
24 V supply
The safety option 30 component does not require an external supply voltage.
Inputs and outputs
The inputs are isolated and designed for a low−voltage supply of 24 V DC.
Detailed features of the safe inputs
Terminal Specification [Unit] min. typ. max.
I1A, I1B
I2A, I2B
AIE, AIS PLC input, IEC−61131−2, 24 V, type 1
Low signal input voltage V −3 0 5
Input current at low signal mA 15
High signal input voltage V 15 24 30
Input current at high signal mA 2 15
Input capacitance nF 3.5
Repetition rate of the test pulses ms 50
AIE, AIS Input delay (operating time) s 0.3 10
24I Voltage supply only for AIE and AIS V 24
CLA, CLB PLC output, IEC−61131−2, 24 V DC, 50 mA
Low signal output voltage V 0 0.8
High signal output voltage V 17 24 29
Output current mA 60
Cable capacity nF 100
Cable resistance of a passive sensor W 200
Safety option 30 does not provide any safe outputs.
