3.2 L_8200Initialization − Frequency inverter initialisation
3−7
L
Lenze8200Drive.lib EN 1.0
3.2 L_8200Initialization − Frequency inverter initialisation
Function block
This FB is used to initialise the frequency inverter with the parameters which were previously defined
by an instance or copy of the FB L_8200Parameter.
Note!
The FB must be called cyclically because the data are internally transmitted to the frequency inverter
via the FBL_ParWrite.
·
Depending on the amount of data to be transmitted, the data transfer may take several cycles.
·
If the data transfer has been successful, the message outputbParDone will be set to TRUE.
·
When the data transfer has been completed ( bParDone = TRUE), the parameterisation is
complete and the FBsL_8200Parameter and L_8200Initialization need not be called again.
L_8200Initialization
abyFraction
anValue
byNoOfParameter
abySubCodeNo
awCodeNo
bExecute
bSelectSDO2Channel
byNodeAddr
CTRL
DATA
nState
bParDone
L
8200
Node address = byNodeAddr
System
bus
(CAN)
FB call in: o Cyclic task
(PLC_PRG)
þ Time−controlled task
(INTERVAL)
o Event−controlled task
(EVENT)
o Interrupt task
Inputs Data type Information/possible settings
bExecute Bool Start data transfer to the frequency inverter
FALSE
ä TRUE
Start data transfer
bSelectSDOChannel Bool Select the parameter channel for the frequency inverter
FALSE SDO 1
TRUE SDO 2
byNodeAddr Byte Device address (1 ... 63) of the frequency inverter to be initialised.
·
See also chapter 2.2.1. ( ^ 2−3)
byNoOfParameter Byte Transfer of the number of parameters to be transmitted
awCodeNo Array of Word Code transfer
abySubCodeNo Byte array Subcode transfer
abyFraction Byte array Transfer of decimal places
·
See also FB description L_ParWrite
in the Manual Function library LenzeDrive.lib.
anValue Array of
integers
Transfer of code values
