Function library Lenze8200Drive.lib
Functions/function blocks
3.1 L_8200Parameter − Initialisation of codes
3−3
L
Lenze8200Drive.lib EN 1.0
Concept I: Parameterisation through direct instructions in the FBs
For this, use the FB L_8200Parameter as template and create a new function block in which the
parameter data are selected by direct assignments.
Note!
Please observe that FB changes (e. g. new assignments) require a new compilation and program
download to the PLC.
·
If you want to change the parameters "online" via the Parameter Monitor or keypad, use
concept II ("Parameterisation by means of codes").
Tip!
The FB L_8200Parameter already includes commented assignments for all parameters relevant
for frequency inverter control.
·
The parameters are listed in the table on the next page.
·
The names of the inputs and outputs of the FBs L_8200CtrlWord and L_8200StatusWord
have been adapted to the selected parameters.
·
If you want to use the pre−assignments, simply copy the assignments to the new FB and
remove the comment characters so that the assignments will become effective.
·
Of course, it is also possible to adapt the assignments to your application.
Proceed as follows:
1. Create a new function block.
2. Use the Library Manager and copy the source code of the FB L_8200Parameter to the new
function block.
3. Remove the comment characters around the assignments to accept the pre−assignments or
adapt the assignments to your application.
FUNCTION_BLOCK Parameter82Device1
VAR_OUTPUT
byNoOfParameter :
BYTE;
awCodeNo :
ARRAY [1..45] OF WORD;
abySubCodeNo :
ARRAY [1..45] OF BYTE;
abyFraction :
ARRAY [1..45] OF BYTE;
anValue :
ARRAY [1..45] OF INT;
END_VAR
(* max. frequency *)
awCodeNo[1]:=11; abySubCodeNo[1]:=0; anValue[1]:=5000; abyFraction[1]:=2;
(* acceleration time Tir *)
awCodeNr[2]:=12; abySubCodeNo[2]:=0; anValue[2]:=0010; abyFraction[2]:=2;
(* deceleration time Tif *)
awCodeNo[3]:=13; abySubCodeNr[3]:=0; anValue[3]:=0010; abyFraction[3]:=2;
(* standardization for C0011 => 16384 *)
awCodeNo[4]:=127; abySubCodeNo[4]:=0; anValue[4]:=1; abyFraction[4]:=0;
...
Fig. 3−1 Example: Source code (extract) of a new FB based on the FB L_8200Parameter
