3.1 L_8200Parameter − Initialisation of codes
Function library Lenze8200Drive.lib
Functions/function blocks
3−2
L
Lenze8200Drive.lib EN 1.0
3.1 L_8200Parameter − Initialisation of codes
Function block
With this FB you can parameterise up to 45 parameters (codes) in the frequency inverter.
The following parameterisation concepts are supported:
·
Parameterisation through direct instructions in the FBs
·
Parameterisation by means of codes ("online" parameterisation possible)
L_8200Parameter
abyFraction
anValue
byNoOfParameter
abySubCodeNo
awCodeNo
1
Code SubCode Fraction Value
2
3
4
5
6
7
8
9
...
45
FB call in: þ Cyclic task
(PLC_PRG)
þ Time−controlled task
(INTERVAL)
þ Event−controlled task
(EVENT)
o Interrupt task
Inputs Data type Information/possible settings
byNoOfParameter Byte Number of parameters to be transmitted (max. 45)
awCodeNo Array of Word Number of the code to be transmitted as parameter 1..45.
abySubCodeNo Byte array Number of the subcode to be transmitted as parameter 1..45.
abyFraction Byte array Number of decimal places for parameters 1..45
·
See also FB description L_ParWrite
in the Manual Function library LenzeDrive.lib.
anValue Array of
integers
Value of the code to be transmitted as parameter 1..45.
