Appendix
Data transfer
Overview of the implemented objects for the function module
9
l
56 EDS82ZAFVCxxx EN 4.0
DeviceNet Class (03
hex
)
Instance 0:
Attribute Service(s) Description Data type Value
1 GET Revision UINT 0002
hex
Instance 1:
Attribute Service(s) Description Data type Value
1 GET MAC ID USINT 0 − 63
2 GET Baud rate USINT 0 − 2
3 GET / SET BOI BOOL 0/1
4 GET Bus−off counter USINT 0 − 255
5 GET Allocation
information Struct of
Allocation choice
byte BYTE 0 – 63
Master’s MAC ID USINT 0 – 63
Services:
Service code Name Description
0E
hex
Get_Attribute_Single Reading of an attribute
10
hex
Set_Attribute_Single Writing of an attribute
4B
hex
Allocate_Master/Slave_Connection_
Set Demands the application of
Predefined Master/Slave Connection
Set"
4C
hex
Release_Group_2_Identifier_Set Connections via Predefined
Master/Slave Connection Set" are
deleted
